JACKPOT
164' (49.99m) CHRISTENSEN
LOA: 164' (49.99m)
Beam: 29' (8.84m)
Max Draft: 8' (2.44m)
Tonnage:
570.00
Speed:
14 Knots
16 Knots
Flag: TBD
Location: N/A, Alaska
United States
Delivery/Model Year: 2020
Builder: CHRISTENSEN
Type:
Motor Yacht
Staterooms: 6
Fuel Cap: 15300 Gal
Water Cap: 3600 Gal
Engines: 2x, MTU, 12V4000 M53, 1810 HP
Price: $39,500,000 USD
www.merlewood.com
801 Seabreeze Boulevard • Bahia Mar Yachting Center, Suite C • Fort Lauderdale, FL 33316 USA • Phone: +1-954-525-5111 • Facsimile: +1-954-525-5165 • Email: mail@merlewood.com
Additional Specifications For JACKPOT:
LOA: 164' (49.99m)
Beam: 29' (8.84m)
Max Draft: 8' (2.44m)
Hull Material: Advanced Composites
Tonnage:
570.00
Range At Cruise Speed: 4000
Speed:
Cruising 14 Knots
Max 16 Knots
Int Designer: Christensen Shipyard
Ext Designer: Christensen Shipyard
Fuel Capacity: 15300 Gal
Water Capacity: 3600 Gal
Flag: TBD
Location: Alaska, United States
Price: $39,500,000 USD
Delivery/Model Year: 2020
Year Built: 2020
Builder: CHRISTENSEN
Type:
Motor Yacht
Engines: 1810 HP,Twin, Inboard, Diesel, MTU, 12V4000 M53,
Staterooms: 6
Sleeps: 16
Captain Cabin: No
Classifications:
American Bureau of Shipping

CONSTRUCTION
Fiberglass hull and superstructure (Vacuum infused FRP-foam core sandwich composite), with teak decks
DIMENSIONS
General
Length Overall:164.00 feet(49.90 meters)
Length at Waterline:149.75 feet(45.60 meters)
Beam (molded):29.00 feet(8.80 meters)
Draft (loaded):8.00 feet(2.40 meters)
Tonnage:570 gross tons
Capacities
Fuel Capacity:15,300 US Gallons(57,916 liters)
Water Capacity:3,600 US Gallons(13,626 liters)
Watermakers:4,800 US Gallons(18,169 liters) per day
Lube Oil:300 US Gallons(1,136 liters)
Waste Oil:300 US Gallons(1,136 liters)
Speed
Maximum:16.5 knots
Cruising:14.0 knots
MACHINERY
Main Engines
Engine Type:(2) MTU12V4000 M53, 1810 HP @ 1800 RPM
Continuous Duty rating, with pre-lube & coolant pre-heat systems.
Gearboxes for Main Engines:(2) ZF Model 4650A, 8º down-angle, 3.04:1 ratio with trailing pumps, trolling valves.
Drive:(2) VEEM - 5 Blades, NiBrAI, CNC machining
Generators & Electricity
Output:208 Volts, 3 phase, 60Hz
Generators:
  • (2) Kohler 99 KW, 208V – 3PH – 60Hz.
  • (1) Kohler 65 KW, 208V – 3PH – 60Hz.
Shore Power:
  • Hyak Electroworks - Integrated shore power & conversion system with full auto-paralleling Control system. Converts any input voltage & frequency from shore power
Batteries:
  • (2) 24 VDC Battery Banks with battery chargers
Air Conditioning
Type:
  • Christensen chilled water HVAC system, with 40-ton chiller with 45-kW electric heater & network interface
Other Machinery
Watermakers:
  • (2) FCI Atlas+ APC, 2400-GPD
Trim Tabs/Stabilizers:
  • Quantum QC-1800, with two (2) custom Stainless Steel high-lift, 4.5 m2 fins
Bow Thruster:
  • ABT TRAC-24” dual-prop tunnel thruster, with 86-KW AC electric motor
Steering System:
  • (2) Jastram electro-hydraulic power packs with emergency manual help pumps
Fuel Separator & Filtration:
  • (2) MTU Primary & Secondary filtration systems
  • (3) Racor model 804MA30 filters for gensets
  • (1) Fuel Filter/Water Separator, Henek Fluid System 30-GPM flow rate
Sewage System:
  • Tecnicomar, model “ECOmar 16”, IMO MEPC-159(55) Certified
Bilge Water System:
  • Recovered Energy Inc., model BOSS2TY-107 USCG Certified, ABS Type-Approved & IMO MEPC-07(49) compliant
Fresh Water Filtration:
  • Carbon Filtration system with Ozone Sterilizer and UV sterilizer

  • FCI DTS+ SOLO water treatment dock side

COMMUNICATION, NAVIGATION & ENTERTAINMENT SYSTEMS
Communication Systems
SATcom:
  • Sailor 100
Telephone System:
  • Panasonic with 24 extension ports for wired & wireless extensions with intercom & paging
VHF:
  • (3) Garmin 300 VHF
Cellular Phone System:
  • (2) Telular SX5E GSM Cellular Phone
Loud Hailer:
  • (1) Garmin

Network Access:

  • Great Circle System NAS 3000 automatically searches all network sources for the most cost effective route for internet traffic
Wireless Network:
  • Cisco 802.11g wireless network covering all decks
Navigation Systems
Vendor:
  • Garmin
Monitors:
  • (7) 24” Hattland monitors
Radar:
  • (1) Furuno FAR2137BB, 30-KW, S-Band
  • (1) Garmin 2526 X-Band, Garmin Fantom 6
  • (1) Garmin GMR Fantom 6
Magnetic Compass:
  • (1) Richie SY-600LL Super Yacht Compass
Auto Pilot:
  • (2) GHP Reactor
Sonar/Sounder:
  • (1) Garmin GSD 25 Advanced Sonar
  • (1) Garmin GSD 26 CHIRP Sonar
  • (2) Garmin GPSMAP 942 with charts
GPS:
  • (4) Garmin GPSMAP 8616 with BlueCart G3 coastal and LakeVu G3 inland maps
Night Vision Camera:
  • (1) FLIR Thermo Voyager
Entertainment System:
Audio/Video Equipment
  • (2) SeaTel 100TVHD Sat TV antennas; Functional control of the entire A/V system is through touch panels located in every room. Each room has autonomous control of the DVD movie library and the CD music library, as well as U.S., Caribbean, and European satellite television. All receiver equipment is located in a central A/V room and networked throughout the yacht.
Monitoring System
  • Hyak Electroworks The programmable logic based system, with (6) 12” color touch-screens installed throughout. A SIMnet integration and monitoring network connects the vessel’s system to allow remote monitoring, data logging, power management and diagnostic.
GALLEY & LAUNDRY EQUIPMENT
Main Galley Equipment
Cooking Equipment:
  • (2) 4-Burner Professional Cooktop
  • (1) Extraction hood with independent fixed fire extinguisher system
  • (2) Convection Ovens
  • (1) Microwave Oven
  • (1) Glo-Ray infrared food warmer
  • (2) Warming drawers
Refrigeration/Freezer:
  • (1) Sub-Zero Refrigerators/Freezers
  • (1) Sub-Zero Ice Maker
  • (1) Manitowoc Ice maker in Pantry
Dishwasher:
  • (2) Miele model
Trash compactor:
  • (2) KitchenAid model
Crew Galley/Mess Equipment
Cooking Equipment:
  • (1) Microwave
  • (1) 4-Burner electric cooktop
Refrigeration/Freezer:
  • (1) Walk-In Cooler/Freezer with (2) Condensing Units
  • (1) Upright Refrigerator / Freezer
Dishwasher:
  • (1) GE model GSD6900JWW
Trash Compactor:
  • KitchenAid model KUCS30CTWH
Laundry Equipment
Main Laundry Equipment
  • (3) Commercial Washers
  • (3) Commercial Dryers
DECK EQUIPMENT
Anchor Windlass System:
  • (2) Maxwell SY-26 windlasses, 15KW electric
Aft Warping Capstans:
  • (6) Maxwell VC-6000 Electric
Anchors:
  • (2) 360KG “Pool N” type, balanced, electro-polished stainless steel
Anchor Chain:
  • (2) 600 feet of 22mm grade-2 stud-link
Boat Crane and Davits:
  • (1) 5000 lbs (2267 kg) capacity – main crane
  • (1) 1200 lbs (544.3 kg) capacity – bow davit
Passerelle:
  • (1) 20’ (6 meter) hydraulic telescoping extension with swivel platform
SECURITY, FIRE FIGHTING & SAFETY EQUIPMENT
Security Equipment
CCTV System:
  • Networked through the A/V control system
Cameras:
  • (10) Sony Network Color Camera with pan-tilt-zoom
Monitors:
  • Cameras can be called up on any TV or monitor onboard via the Creston switching system
Fire Fighting Equipment
Fire Control System:
  • Novenco XFlow water mist system in all Living spaces FM-200 fixed fire Extinguishing System in the Engine Room and Generator Room
Fire Extinguishers:
  • Provided throughout as required by ABS
Alarms:
  • Consilium Salwico CS4000, with smoke, heat and Flame detectors where necessary
Safety Equipment
Life Rafts:
  • (4) Zodiac 16 person USCG and SOLAS approved
Life Rings:
  • (4) SOLAS approved
EPIRBS:
  • ACR 2742 (CAT 1 with GPS)
Flares:
  • Per MCA requirements
